3-way stainless steel ball valve with L-port or T-port for shut-off, mixing, or diverting fluids in chemical networks, petrochemical industries, hydraulic systems, heating, and air and water distribution.
Sealing is ensured by a PTFE gland packing and an FPM O-ring on the stem, as well as by seats made of 15% glass-filled PTFE. The valve can be actuated by an actuator mounted directly on the ISO 5211 pad via the square stem.
| Body | Stainless steel EN 1.4408 | |
| Ball | AISI 316 | |
| Control valve spindle | Blow-out proof, stainless steel 316, PTFE and FPM sealing | |
| Seats | 15% glass-filled PTFE | |
| Coupling | BSP threaded | |
| Dimensions | DN1/4" to DN2" | |
| Working pressure | 40 bar | |
| Temperature | from -20 to +180°C | |
| Standards: | Directive 2014/68/EU: CE No. 0036 Risk category II, Module A2 |
